Overview

OpenAI is the baseline schema for Vikat. When using OpenAI directly, parameters are passed through with minimal conversion - mostly validation and filtering of OpenAI-specific features.

Supported Operations

Operation	Non-Streaming	Streaming	Endpoint
Chat Completions	✅	✅	`/v1/chat/completions`
Responses API	✅	✅	`/v1/responses`
Text Completions	✅	✅	`/v1/completions`
Embeddings	✅	-	`/v1/embeddings`
Speech (TTS)	✅	✅	`/v1/audio/speech`
Transcriptions (STT)	✅	✅	`/v1/audio/transcriptions`
Image Generation	✅	✅	`/v1/images/generations`
Image Edit	✅	✅	`/v1/images/edits`
Image Variation	✅	-	`/v1/images/variations`
Files	✅	-	`/v1/files`
Batch	✅	-	`/v1/batches`
Video Generation	✅	-	`/v1/videos`
Context Compaction	✅	-	`/v1/responses/compact`
List Models	✅	-	`/v1/models`

Setup & Configuration

Configure OpenAI as a provider.

Web UI
config.json
API
Go SDK

Navigate to Models > Model Providers. Look for OpenAI under Configured Providers. If it is missing, click on Add New Provider and select OpenAI.
Click Add Key or edit an existing key.
Set a name for your key.
Paste your API key directly or use an environment variable (for example, env.OPENAI_API_KEY).
Set Allowed Models to All Models (default) or the specific model allowlist you want this key to serve.
Save the provider configuration.

{
  "providers": {
    "openai": {
      "keys": [
        {
          "name": "openai-key-1",
          "value": "env.OPENAI_API_KEY",
          "models": [
            "*"
          ],
          "weight": 1.0
        }
      ],
      "openai_config": {
        "disable_store": false
      }
    }
  }
}

case schemas.OpenAI:
    return []schemas.Key{{
        Name:   "openai-key-1",
        Value:  *schemas.NewSecretVar("env.OPENAI_API_KEY"),
        Models: []string{"*"},
        Weight: 1.0,
    }}, nil

Optional provider settings include network_config for timeouts, retries, proxy/TLS settings, and openai_config.disable_store to force store=false on outgoing OpenAI requests.

1. Chat Completions

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`messages`	array	✅	`ChatMessage` array with roles (docs)
`temperature`	float	❌	Sampling temperature (0-2)
`top_p`	float	❌	Nucleus sampling parameter
`stop`	string/array	❌	Stop sequences
`max_completion_tokens`	int	❌	Min 16, max output tokens
`frequency_penalty`	float	❌	Frequency penalty (-2 to 2)
`presence_penalty`	float	❌	Presence penalty (-2 to 2)
`logit_bias`	object	❌	Token logit adjustments
`logprobs`	bool	❌	Include log probabilities
`top_logprobs`	int	❌	Number of log probabilities per token
`seed`	int	❌	Reproducibility seed
`response_format`	object	❌	Output format (docs)
`tools`	array	❌	`Tool` objects (docs)
`tool_choice`	string/object	❌	`"auto"`, `"none"`, `"required"`, or specific tool
`parallel_tool_calls`	bool	❌	Allow multiple simultaneous tool calls
`stream_options`	object	❌	Streaming options (docs)
`reasoning`	object	❌	Reasoning parameters (Vikat docs, OpenAI docs)
`user`	string	❌	Truncated to 64 chars
`metadata`	object	❌	Custom metadata
`store`	bool	❌	Filtered for non-OpenAI routing
`service_tier`	string	❌	Filtered for non-OpenAI routing
`prompt_cache_key`	string	❌	Filtered for non-OpenAI routing
`prediction`	object	❌	Predicted output for acceleration
`audio`	object	❌	Audio output config
`modalities`	array	❌	Response modalities (text, audio)

Reasoning: OpenAI supports reasoning.effort (minimal, low, medium, high) and reasoning.max_tokens - both passed through directly. When routing to other providers, "minimal" effort is converted to "low" for compatibility. See Vikat reasoning docs.
Messages: All message roles are supported: system, user, assistant, tool, developer (treated as system). Content types: text, images via URL (image_url), audio input (input_audio). Tool messages include a tool_call_id.
Tools: Standard OpenAI tool format with strict mode support. Tool choice: "auto", "none", "required", or specific tool by name.
Responses: Passed through in standard OpenAI format. Finish reasons: stop, length, tool_calls, content_filter. Usage includes token counts and optionally cached/reasoning token details.
Streaming: Server-Sent Events format with delta.content, delta.tool_calls, finish_reason, and usage (final chunk only, automatically included by Vikat). stream_options: { include_usage: true } is set by default for all streaming calls.
Cache Control: cache_control fields are stripped from messages, their content blocks, and tools before sending.
Token Enforcement: max_completion_tokens is enforced to have a minimum of 16. Values below 16 are automatically set to 16.
Special handling: user field is truncated to 64 characters; prompt_cache_key, store, service_tier are filtered when routing to non-OpenAI providers

2. Responses API

The Responses API is OpenAI’s structured output API. Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`input`	string/array	✅	Text or `ContentBlock` array (docs)
`max_output_tokens`	int	✅	Maximum output length
`background`	bool	❌	Run request in background mode
`conversation`	string	❌	Conversation ID for continuing a conversation
`include`	array	❌	Array of fields to include in response (e.g., `"web_search_call.action.sources"`)
`instructions`	string	❌	System instructions
`max_tool_calls`	int	❌	Maximum number of tool calls
`metadata`	object	❌	Custom metadata
`parallel_tool_calls`	bool	❌	Allow multiple simultaneous tool calls
`previous_response_id`	string	❌	ID of previous response to continue from
`prompt_cache_key`	string	❌	Prompt caching key
`reasoning`	object	❌	`ResponsesParametersReasoning` configuration (Vikat docs)
`safety_identifier`	string	❌	Safety identifier for content filtering
`service_tier`	string	❌	Service tier for the request
`stream_options`	object	❌	`ResponsesStreamOptions` configuration
`store`	bool	❌	Store the response for later retrieval
`temperature`	float	❌	Sampling temperature
`text`	object	❌	`ResponsesTextConfig` for output formatting
`top_logprobs`	int	❌	Number of log probabilities to return per token
`top_p`	float	❌	Nucleus sampling parameter
`tool_choice`	string/object	❌	`ResponsesToolChoice` strategy
`tools`	array	❌	`ResponsesTool` objects (docs)
`truncation`	string	❌	Truncation strategy (`auto` or `off`)
`user`	string	❌	Truncated to 64 chars

Special Message Handling (gpt-oss vs other models): OpenAI models handle reasoning differently depending on the model family:

Non-gpt-oss models (GPT-4o, o1, etc.): Send reasoning as summaries. Reasoning-only messages (with no summary and only content blocks) are filtered out since these models don’t support reasoning content blocks in the request format.
gpt-oss models: Send reasoning as content blocks. Reasoning summaries in the request are converted to content blocks since gpt-oss expects reasoning as structured blocks, not summaries.

This conversion ensures compatibility across different model architectures for the structured Responses API. See Vikat reasoning docs for detailed reasoning handling. Token & Parameter Enforcement:

max_output_tokens is enforced to have a minimum of 16. Values below 16 are automatically set to 16.
reasoning.max_tokens field is automatically removed from JSON output (OpenAI Responses API doesn’t accept it).

Other conversions:

Action types zoom and region are converted to screenshot
cache_control fields are stripped from messages and tools
Unsupported tool types are silently filtered (only these are supported: function, file_search, computer_use_preview, web_search, mcp, code_interpreter, image_generation, local_shell, custom, web_search_preview)

Response: Includes id, status (completed, incomplete, pending, error), output array with message content, and token usage. Streaming: Server-Sent Events with types: response.created, response.in_progress, response.output_item.added, response.content_part.added, response.output_text.delta, response.function_call_arguments.delta, response.completed, response.incomplete. stream_options: { include_usage: true } is set by default for all streaming calls.

3. Text Completions (Legacy)

Text Completions is a legacy API. Use Chat Completions for new implementations.

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`prompt`	string/array	✅	Completion prompt(s)
`max_tokens`	int	❌	Maximum output tokens
`temperature`	float	❌	Sampling temperature
`top_p`	float	❌	Nucleus sampling
`stop`	string/array	❌	Stop sequences
`user`	string	❌	Truncated to 64 chars

Array prompts generate multiple completions. Finish reasons: stop or length. Streaming uses SSE format. stream_options: { include_usage: true } is set by default for streaming calls.
user field is truncated to 64 characters or set to nil if it exceeds the limit.

4. Embeddings

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`input`	string/array	✅	Text(s) to embed (docs)
`encoding_format`	string	❌	`float` or `base64`
`dimensions`	int	❌	Output embedding dimensions
`user`	string	❌	NOT truncated (unlike chat/text)

No streaming support. Returns embedding array with usage counts.

5. Speech (Text-to-Speech)

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	`tts-1` or `tts-1-hd`
`input`	string	✅	Text to convert to speech
`voice`	string	✅	alloy, echo, fable, onyx, nova, shimmer
`response_format`	string	❌	mp3, opus, aac, flac, wav, pcm
`speed`	float	❌	0.25 to 4.0 (default 1.0)

Returns raw binary audio. Streaming supported in SSE format (base64 chunks), but not all models support streaming. stream_options: { include_usage: true } is set by default for streaming calls.

6. Transcriptions (Speech-to-Text)

Requests use multipart/form-data, not JSON.

Request Parameters

Parameter	Type	Required	Notes
`file`	binary	✅	Audio file (multipart form-data)
`model`	string	✅	`whisper-1`
`language`	string	❌	ISO-639-1 language code
`prompt`	string	❌	Optional prompt for context
`temperature`	float	❌	Sampling temperature
`response_format`	string	❌	json, text, srt, vtt, verbose_json

Supported audio formats: mp3, mp4, mpeg, mpga, m4a, wav, webm
Response: Includes text, task, language, duration, and optionally word-level timing. Streaming supported in SSE format. stream_options: { include_usage: true } is set by default for streaming calls.

7. Image Generation

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier (e.g., `dall-e-3`)
`prompt`	string	✅	Text description of the image to generate
`n`	int	❌	Number of images to generate (1-10)
`size`	string	❌	Image size: `"256x256"`, `"512x512"`, `"1024x1024"`, `"1792x1024"`, `"1024x1792"`, `"1536x1024"`, `"1024x1536"`, `"auto"`
`quality`	string	❌	Image quality: `"auto"`, `"high"`, `"medium"`, `"low"`, `"hd"`, `"standard"`
`style`	string	❌	Image style: `"natural"`, `"vivid"`
`response_format`	string	❌	Response format: `"url"` or `"b64_json"`
`background`	string	❌	Background: `"transparent"`, `"opaque"`, `"auto"`
`output_format`	string	❌	Output format: `"png"`, `"webp"`, `"jpeg"`
`output_compression`	int	❌	Compression level (0-100%)
`partial_images`	int	❌	Number of partial images (0-3)
`moderation`	string	❌	Moderation level: `"low"`, `"auto"`
`user`	string	❌	User identifier

Request Conversion OpenAI is the baseline schema for image generation. Parameters are passed through with minimal conversion:

Model & Prompt: vikatReq.Model → req.Model, vikatReq.Prompt → req.Prompt
Parameters: All fields from vikatReq (ImageGenerationParameters) are embedded directly into the OpenAI request struct via struct embedding. No field mapping or transformation is performed.
Streaming: When streaming is requested, stream: true is set in the request body.

Response Conversion

Non-streaming: OpenAI responses are unmarshaled directly into VikatImageGenerationResponse since Vikat’s response schema is a superset of OpenAI’s format. All fields are passed through as-is.
Streaming: OpenAI streaming responses use Server-Sent Events (SSE) format with event types:
- image_generation.partial_image: Intermediate image chunks with b64_json data
- image_generation.completed: Final chunk for each image with usage information
- error: Error events
Each chunk includes:
- type: Event type
- sequence_number: Sequence number of the chunk
- partial_image_index: Image index (0-N) for partial images
- b64_json: Base64-encoded image data (pointer, may be nil)
- usage: Token usage (only in completed events)
- created_at, size, quality, background, output_format: Additional metadata
Vikat converts these to VikatImageGenerationStreamResponse chunks with:
- Per-image chunkIndex tracking for proper ordering within each image
- Index field indicating which image (0-N) the chunk belongs to
- PartialImageIndex set only for partial images (not completed events)
- Usage information attached to completed chunks
- Latency tracking per chunk

Endpoint: /v1/images/generations

8. Image Edit

Requests use multipart/form-data, not JSON.

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`prompt`	string	✅	Text description of the edit
`image[]`	binary	✅	Image file(s) to edit (multipart form-data, supports multiple images)
`mask`	binary	❌	Mask image file (multipart form-data)
`n`	int	❌	Number of images to generate (1-10)
`size`	string	❌	Image size: `"256x256"`, `"512x512"`, `"1024x1024"`, `"1536x1024"`, `"1024x1536"`, `"auto"`
`quality`	string	❌	Image quality: `"auto"`, `"high"`, `"medium"`, `"low"`, `"standard"`
`response_format`	string	❌	Response format: `"url"` or `"b64_json"`
`background`	string	❌	Background: `"transparent"`, `"opaque"`, `"auto"`
`input_fidelity`	string	❌	Input fidelity: `"low"`, `"high"`
`partial_images`	int	❌	Number of partial images (0-3)
`output_format`	string	❌	Output format: `"png"`, `"webp"`, `"jpeg"`
`output_compression`	int	❌	Compression level (0-100%)
`user`	string	❌	User identifier
`stream`	bool	❌	Enable streaming response

Request Conversion

Model & Input: vikatReq.Model → req.Model, vikatReq.Input.Images → req.Input.Images, vikatReq.Input.Prompt → req.Input.Prompt
Parameters: All fields from vikatReq.Params (ImageEditParameters) are embedded directly into the OpenAI request struct via struct embedding. No field mapping or transformation is performed.
Multipart Form Data: The request is serialized as multipart/form-data:
- Model & Prompt: Written as form fields (model, prompt)
- Images: Each image in Input.Images is written as a separate image[] field with proper MIME type detection (image/jpeg, image/webp, image/png) and Content-Type headers
- Mask: If present, written as a mask field with MIME type detection and appropriate filename (mask.png, mask.jpg, mask.webp)
- Optional Parameters: All optional parameters (n, size, quality, response_format, background, input_fidelity, partial_images, output_format, output_compression, user) are written as form fields
- Integer Conversion: Integer fields (n, partial_images, output_compression) are converted to strings using strconv.Itoa
- Streaming: When streaming is requested, stream: "true" is written as a form field

Response Conversion

Non-streaming: OpenAI responses are unmarshaled directly into VikatImageGenerationResponse since Vikat’s response schema is a superset of OpenAI’s format. All fields are passed through as-is.
Streaming: OpenAI streaming responses use Server-Sent Events (SSE) format with event types:
- image_edit.partial_image: Intermediate image chunks with b64_json data
- image_edit.completed: Final chunk for each image with usage information
- error: Error events
Each chunk includes:
- type: Event type (image_edit.partial_image or image_edit.completed)
- sequence_number: Sequence number of the chunk
- partial_image_index: Image index (0-N) for partial images
- b64_json: Base64-encoded image data (pointer, may be nil)
- usage: Token usage (only in completed events)
Vikat converts these to VikatImageGenerationStreamResponse chunks with:
- Per-image chunkIndex tracking for proper ordering within each image
- Index field indicating which image (0-N) the chunk belongs to
- PartialImageIndex set only for partial images (not completed events)
- Usage information attached to completed chunks
- Latency tracking per chunk
- Robust handling of interleaved chunks using incomplete image tracking

Endpoint: /v1/images/edits

9. Image Variation

Requests use multipart/form-data, not JSON.

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`image`	binary	✅	Image file to create variations from (multipart form-data)
`n`	int	❌	Number of images to generate (1-10)
`size`	string	❌	Image size: `"256x256"`, `"512x512"`, `"1024x1024"`, `"1792x1024"`, `"1024x1792"`, `"1536x1024"`, `"1024x1536"`, `"auto"`
`response_format`	string	❌	Response format: `"url"` or `"b64_json"`
`user`	string	❌	User identifier

Request Conversion

Model & Input: vikatReq.Model → req.Model, vikatReq.Input.Image.Image → req.Input.Image.Image
Parameters: All fields from vikatReq.Params (ImageVariationParameters) are embedded directly into the OpenAI request struct via struct embedding. No field mapping or transformation is performed.
Multipart Form Data: The request is serialized as multipart/form-data:
- Model: Written as form field (model)
- Image: The image is written as an image field with proper MIME type detection (image/jpeg, image/webp, image/png) and Content-Type headers. If MIME type cannot be detected, defaults to image/png
- Optional Parameters: All optional parameters (n, size, response_format, user) are written as form fields
- Integer Conversion: Integer field (n) is converted to string using strconv.Itoa
Multiple Images: Additional images beyond the first one (if present in ExtraParams["images"]) are stored in ExtraParams but only the first image is sent to OpenAI (OpenAI API only supports single image input)

Response Conversion

Non-streaming: OpenAI responses are unmarshaled directly into VikatImageVariationResponse (which is a type alias for VikatImageGenerationResponse). All fields are passed through as-is.
Streaming: Not supported for image variation requests.

Endpoint: /v1/images/variations

10. Files API

Upload

Request Parameters

Parameter	Type	Required	Notes
`file`	binary	✅	File to upload (multipart form-data)
`purpose`	string	✅	batch, fine-tune, or assistants
`filename`	string	❌	Custom filename (defaults to file.jsonl)

Response: FileObject with id, bytes, created_at, filename, purpose, status (docs)

List Files

Query Parameters

Parameter	Type	Required	Notes
`purpose`	string	❌	Filter by purpose
`limit`	int	❌	Results per page
`after`	string	❌	Pagination cursor
`order`	string	❌	asc or desc

Cursor-based pagination with has_more flag.

Retrieve / Delete / Content

Operations:

GET /v1/files/{file_id} - Retrieve file metadata
DELETE /v1/files/{file_id} - Delete file
GET /v1/files/{file_id}/content - Download file content

11. Batch API

Create Batch

Request Parameters

Parameter	Type	Required	Notes
`input_file_id`	string	Conditional	File ID OR requests array (not both)
`requests`	array	Conditional	`BatchRequestItem` objects (converted to JSONL)
`endpoint`	string	✅	Target endpoint (e.g., /v1/chat/completions)
`completion_window`	string	❌	24h (default)
`metadata`	object	❌	Custom metadata

Response: VikatBatchCreateResponse with id, endpoint, input_file_id, status, created_at, request_counts (docs). Statuses: BatchStatus (validating, failed, in_progress, finalizing, completed, expired, cancelling, cancelled)

List Batches

Query Parameters

Parameter	Type	Required	Notes
`limit`	int	❌	Results per page
`after`	string	❌	Pagination cursor

Retrieve / Cancel Batch

Operations:

GET /v1/batches/{batch_id} - Get batch VikatBatchRetrieveResponse (docs)
POST /v1/batches/{batch_id}/cancel - Cancel batch (docs)

Get Results

Batch must be completed (has output_file_id)
Download output file via Files API
Parse JSONL - each BatchResultItem: {id, custom_id, response: {status_code, body}}

12. List Models

GET /v1/models - Lists available models with metadata. Model IDs in Vikat responses are prefixed with openai/ (e.g., openai/gpt-4o). Results are aggregated from all configured API keys. No request body or parameters required.

13. Video Generation

Generate (`POST /v1/videos`)

Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	e.g., `sora-2`
`prompt`	string	✅	Text description of the video
`seconds`	string	❌	Duration in seconds
`size`	string	❌	Resolution: `720x1280` (default), `1280x720`, `1024x1792`, `1792x1024`

Response: VikatVideoGenerationResponse - id, status, model, prompt, created_at Job Statuses: queued → in_progress → completed / failed

Retrieve / Download / Delete / List / Remix

Operation	Endpoint	Notes
Get status	`GET /v1/videos/{id}`	Poll until `status: completed`
Download	`GET /v1/videos/{id}/content`	Returns raw video bytes
Delete	`DELETE /v1/videos/{id}`	Removes video job
List jobs	`GET /v1/videos`	Query params: `after`, `limit`, `order`
Remix	`POST /v1/videos/{id}/remix`	Body: `{"prompt": "..."}`

14. Context Compaction

Compresses a conversation into an opaque encrypted item that can be reused in future Responses API calls, reducing token costs for long-running conversations. Request Parameters

Parameter	Type	Required	Notes
`model`	string	✅	Model identifier
`input`	string/array	✅*	Conversation to compact. Required unless `previous_response_id` is set. Accepts the same format as the Responses API `input` field, including prior compaction items (`type: "response.compaction"`).
`previous_response_id`	string	✅*	ID of a previously stored response to compact instead of sending full input.
`instructions`	string	❌	System instructions preserved across the compacted context.
`prompt_cache_key`	string	❌	Prompt caching key.
`prompt_cache_retention`	string	❌	Cache retention duration.
`service_tier`	string	❌	Service tier preference.
`fallbacks`	array	❌	Vikat fallback model list.

Endpoint: POST /v1/responses/compact

Common Error Codes

HTTP Status → Error Type mapping:

400 - invalid_request_error
401 - authentication_error
403 - permission_error
404 - not_found_error
429 - rate_limit_error
500 - api_error

Overview

Quick Start

Release Cadence

Migration Guides

SDK Integrations

Providers & Guides

MCP Gateway

Custom plugins

Open Source Features

OpenAI

Overview

Supported Operations

Setup & Configuration

1. Chat Completions

2. Responses API

3. Text Completions (Legacy)

4. Embeddings

5. Speech (Text-to-Speech)

6. Transcriptions (Speech-to-Text)

7. Image Generation

8. Image Edit

9. Image Variation

10. Files API

Upload

List Files

Retrieve / Delete / Content

11. Batch API

Create Batch

List Batches

Retrieve / Cancel Batch

Get Results

12. List Models

13. Video Generation

Generate (`POST /v1/videos`)

Retrieve / Download / Delete / List / Remix

14. Context Compaction

Common Error Codes

​Overview

​Supported Operations

​Setup & Configuration

​1. Chat Completions

​2. Responses API

​3. Text Completions (Legacy)

​4. Embeddings

​5. Speech (Text-to-Speech)

​6. Transcriptions (Speech-to-Text)

​7. Image Generation

​8. Image Edit

​9. Image Variation

​10. Files API

​Upload

​List Files

​Retrieve / Delete / Content

​11. Batch API

​Create Batch

​List Batches

​Retrieve / Cancel Batch

​Get Results

​12. List Models

​13. Video Generation

​Generate (POST /v1/videos)

​Retrieve / Download / Delete / List / Remix

​14. Context Compaction

​Common Error Codes

Overview

Supported Operations

Setup & Configuration

1. Chat Completions

2. Responses API

3. Text Completions (Legacy)

4. Embeddings

5. Speech (Text-to-Speech)

6. Transcriptions (Speech-to-Text)

7. Image Generation

8. Image Edit

9. Image Variation

10. Files API

Upload

List Files

Retrieve / Delete / Content

11. Batch API

Create Batch

List Batches

Retrieve / Cancel Batch

Get Results

12. List Models

13. Video Generation

Generate (`POST /v1/videos`)

Retrieve / Download / Delete / List / Remix

14. Context Compaction

Common Error Codes
